Product features

H Model

H Model - Bucket Elevator

Thanks to the buckets attached to the belt in the bucket elevator, it allows the grains to be transported vertically. Our elevators work quietly at high capacity with lower energy consumption.

  • H Model

    Our H Model elevators are driven by shaft mounted helical reducer with belt pulley connection.

    Since pulleys of different diameters can be used, different speeds and capacities are obtained.

    Technical Service is easy.

Resmi Görüntüle
  • Daha Fazlası

    drive

    The drive head is driven both as a belt pulley (KK Series) and coupled (AR Series).

    Thanks to the return lock, the back-up of the system is prevented in case of power failure, thus providing ease of maintenance.

    Close
  • Daha Fazlası

    Column

    It is specially designed against water and dust tightness.

    Close
  • Daha Fazlası

    Aquarius

    Our buckets, produced from high-density polyethylene, are flexible, durable, long-lasting against abrasion and have anti-static properties.

    Close
  • Daha Fazlası

    Strap

    Our belts have anti-static properties to minimize dust explosion.

    Close
  • Daha Fazlası

    Wanderer Head

    The drive sub-head made of galvanized steel has a strong structure supported by special profiles.

    Close
Capacity

The bucket elevator has different models and product options from 25 t/h to 1000 t/h.

Structural Feature

Our bucket elevators are manufactured from galvanized sheet, so they are highly resistant to environmental factors.
Thanks to the anti-static feature of our high-density polyethylene buckets and belts, they are designed to last longer than their counterparts.
It has a modular and standard structure.
In general, our Maxporter bucket elevators are environmentally friendly and designed in accordance with occupational health and safety rules.
According to the motor connections, coupled (A series) belt connection (C series) 2 connections are offered.

Easy Operation

Due to the modular and standard structure of our designs, spare parts supply and technical service are easy.

Technicial Specifications

You can reach the capacity table of the product by clicking the letters in the picture.
Capacity Table
  • Format
    • Table Format
Tablonun devamını görmek için yana kaydırınız.
CODE DIA CAPACITY A B C D E G H I J K
31G-25 314 33 1090 1540 900 *** 296 168 168 168 168 1250
53H-50 530 65 1600 1950 1030 292 350 219 219 219 219 1930
63J-100 630 130 1750 2400 1025 267 400 273 273 273 273 1167
79K-150 790 195 2250 2900 1450 367 450 323 323 323 323 1367
97K-200 970 260 2500 3300 1450 367 450 323 323 323 323 1367
107M-300 1070 390 2750 3600 1700 330 550 406 406 406 406 1530
122L-400 1220 520 2800 3700 1700 330 990 457 457 457 457 1730
122L-400 1220 520 2800 3700 1700 330 990 457 457 457 457 1730
107M2-500 1070 650 2850 3700 1700 330 670 457 457 457 457 1730
122M2-600 1220 780 2850 3700 1700 330 990 508 508 508 508 1730
122M2-700 1220 910 2850 3700 1700 330 990 508 508 508 508 1730
122M2-800 1220 1040 2850 3700 1700 330 1190 609 609 609 609 1730
122M2-900 1220 1170 2850 3700 1700 330 1190 609 609 609 609 1730
122M3-1000 1220 1300 2850 3700 1700 330 1500 609 609 609 609 1730
122L3-1000 1220 1560 2850 3700 1700 330 1810 609 609 609 609 1730
Our Unit of Capacity is m³/h.
Diameters found in the table are specified as drum diameter.
Dimensions are in mm.
Maxporter reserves the right to change specifications.
Distance x between Inlet and Discharge chamber is variable depending on the project.
